规范
| 功能参数 | |
| 标称 Battery Energy | 3900wh |
| 标称 容量 | 65安时 |
| 标称 电压 | 60伏 |
| 内部阻力 | ≤22mΩ |
| 循环寿命 | >6000 |
| 月自放电 | <3％ |
| 充电数据 | |
| 直流正常充电电压 | 54.75±1Vdc |
| 充电方式 | 0.2C 至 54.75V，然后 54.75V，充电电流至 0.02C (CC/CV) |
| 推荐充电器电流 | ≤50A |
| 允许的最大值充电电流 | 50ADC |
| 充电截止电压 | 54.75±1Vdc |
| 放电数据 | |
| 连续放电电流 | 50A |
| 允许的最大值放电电流 | 100A（选项：100Adc） |
| 直流放电电压范围 | 37.5V-54.75Vdc |
| 工作条件 | |
| 充电温度 | 0℃ 至 45℃（32℉ 至 113℉）@60±25% 相对湿度 |
| 放电温度 | -20℃ 至 60℃（-4℉ 至 140℉）@60±25% 相对湿度 |
| 贮存温度 | 0℃ 至 40℃（32℉ 至 104℉）@60±25% 相对湿度 |
| 外壳防护等级 | IP67 |
特征
1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less
优点
1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect
我们可以为您提供定制服务
Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK
容量及尺寸可根据您的要求定制：
1.定制电池尺寸和外壳材料
2.定制BMS充放电电流
3.定制连接插头和插座，连接器线
| AIN 锂电池组主要应用 | |
| 电动推进应用 | 发动机启动电池；慢速车智能机器人；电动自行车/摩托车/踏板车；高尔夫手推车/小推车/观光车;电动工具。 |
| 储能 | 太阳能和风力发电系统；城市开/关网格；社区和家庭，RV大篷车，海上游艇。 |
| 备用系统和UPS | Telecommute base, CATV-system, computer server center, medical instrument, military equipment. |
| 其他应用 | 安全和电子；移动POS，矿灯/手电筒/ LED灯/应急灯。 |
我们公司
WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.
6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.
常问问题
问: 你们的保修是什么？
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.
Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.
Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
100％安全付款
