72v 40ah 锂电池适用于智能电动摩托车电池

2024-02-29 02:27

规范

1. Technical Data
额定电压	72伏
额定容量	40Ah
Cells	G25 Cells
BMS	60A
组合	20S16P
Discharge Cut-Off Voltage	56V Customize DIY E-Scooter lithium Battery 24V 36V 48V 60V 72V Ebike Bicycle Battery Pack for 1000W 2000W 3000W Motorcycle
Charge Cut-Off Voltage	84伏
标准充电电流	4A 72V 40Ah waterproof battery motorcycle electric scooter battery scooter battery removable x7 scooter battery
最大充电电流	5A
循环寿命	80% power after 600-1000 cycles
应用	72V 3000W Motor
2. Basic Data
尺寸	410*180*150mm
电池净重	16KG
Battery Material	Li(NiCoMn)O2, 18650
保证	12 moths and longer, offer local repair in  US and Germany
充电温度	0 ~ 45 Celsius
出料温度	-20 ~ 60 Celsius Lithium ion Battery Pack 36V 48V 60V 72V 20Ah 30Ah 40Ah Electric Motorcycle for Scooter
3. Packing List
Battery * 1PC
84V 4A Charger with US/UK/EU/AU plug * 1PC



1.Battery Characteristics

* Our batteries use original Brand New Grade A cells.
* They have a built-in UPS function and accurate data BMS management system.
* No need to calculate working time; the LED screen shows remaining working time.
* Error is within 1% (most power stations have 10-20% error).

2. Delivery Time

* Samples with brand design: 3-15 days express delivery after payment.
* OEM/ODM orders: 15-45 days due to detailed discussions.

3. Payment Terms

* 100% payment before shipment (mass order: 30% deposit before sending).
* Payment methods: TT, Western Union, Alipay, etc.

4. Technical Support

* Lifetime online support through Whatsapp, Skype, Wechat, and Email.
* Professional engineers team for the best solutions.



应用

我们的工厂

包装和运输

常问问题

1.What distance can I get on a battery single charge ?

有很多因素可以决定电动自行车的行驶距离，风速，重量，山丘，地形，是否使用踏板助力还是仅使用油门功率和电池大小。最重要的是电池容量，大多数现代电动自行车一次充电至少可以行驶40公里至80公里。

2.您想旅行多长时间？

理论上我们只能计算距离，实际距离取决于很多因素。

短途旅行，从20公里到50公里，选择10Ah – 15Ah电池左右。
行程更长，从32公里到80公里，请选择16Ah电池。
非常长的行程，请与我们联系以进行计算。

3.是否有保修？
当然是。创建运输标签后，我们提供12个月的保修。

4.如果在工作期间电池爆炸或着火，我可以得到赔偿吗？
Since our establishment five years ago, there have been only two explosions due to users opening the battery pack without authorization. Therefore, please do not open the battery pack without permission. If it is normal use, an explosion occurs and the loss exceeds 5000 USD, we can apply for compensation from the insurance company. This will hardly happen.

5.给电池充电需要多长时间？电池可持续使用多长时间？
充电时间=电池的额定容量/充电电流+ 0.5小时（慢速充电时间）
例如48V 10Ah电池。如果使用2A充电器充电，则充电时间= 10/2 + 0.5 = 5.5小时。如果使用4A充电器充电，则充电时间需要10/4 + 0.5 = 3小时。
电池和充电器只能在清洁，干燥和通风良好的环境中使用，并且要高于冰点和低于40摄氏度。电池和充电器都会在充电过程中变热，并且切勿覆盖任何会使它们发热的物品。

6. Are AIN E-BIKE Batteries water proof? Can I ride them in the rain?
All AIN Batteries are sealed well enough to be safely ridden in light rain.
但是，不建议骑车穿越倾盆大雨，泛滥的街道甚至被水淹没。这可能会使某些电气连接短路，并严重损坏电气系统。最好躲藏直到雨水缓和并且道路不再被水覆盖。
